Model

Current(A)

Voltage(V)

Package

VF@I   25℃

VF@I   125℃

Trr(ns)

IR(uA)25℃

IR(mA)125℃

IFSM(A)

Tj(℃)

Download

MUR1620CT

16

200

TO-220AB

1.0V@8A

0.8V@8A

35

10

0.1

150

-55 to +150

MUR1620CTR

16

200

TO-220AB

1.0V@8A

0.8V@8A

35

10

0.1

150

-55 to +150

MUR3030PT

30

300

TO-247

1.1V@15A

1.05V@15A

50

10

0.5

200

-55 to +150

MUR3030PTR

30

300

TO-247

1.1V@15A

1.05V@15A

50

10

0.5

200

-55 to +150

MUR4030PT

40

300

TO-247

1.15V@20A

1.05V@20A

50

10

0.5

250

-55 to +150

MUR4030PTR

40

300

TO-247

1.15V@20A

1.05V@20A

50

10

0.5

250

-55 to +150

MUR6030PT

60

300

TO-247

1.1V@30A

1.0V@30A

50

10

0.5

300

-55 to +150

MUR6030PTR

60

300

TO-247

1.1V@30A

1.0V@30A

50

10

0.5

300

-55 to +150

MUR3040PT

30

400

TO-247

1.35V@15A

1.15V@15A

50

10

0.5

200

-55 to +150

MUR3040PTR

30

400

TO-247

1.35V@15A

1.15V@15A

50

10

0.5

200

-55 to +150

MUR3040CT

30

400

TO-220AB

1.35V@15A

1.15V@15A

50

5

0.25

250

-55 to +150

MUR3040CTR

30

400

TO-220AB

1.35V@15A

1.15V@15A

50

5

0.25

250

-55 to +150

MUR4040PT

40

400

TO-247

1.35V@20A

1.15V@20A

50

10

0.5

300

-55 to +150

MUR4040PTR

40

400

TO-247

1.35V@20A

1.15V@20A

50

10

0.5

300

-55 to +150

MUR6040PT

60

400

TO-247

1.35@30A

1.15V@30A

50

10

0.5

460

-55 to +150

MUR6040PTR

60

400

TO-247

1.35@30A

1.15V@30A

50

10

0.5

460

-55 to +150

MUR1060CTF

10

600

TO-220F

1.7V@5A

1.5V@5A

35

5

0.25

150

-55 to +150

MUR1060CTFR

10

600

TO-220F

1.7V@5A

1.5V@5A

35

5

0.25

150

-55 to +150

MUR1060CT

10

600

TO-220AB

1.7V@5A

1.5V@5A

35

5

0.25

150

-55 to +150

MUR1060CTR

10

600

TO-220AB

1.7V@5A

1.5V@5A

35

5

0.25

150

-55 to +150

MUR1660CT

16

600

TO-220AB

1.7V@8A

1.5V@8A

35

5

0.05

250

-55 to +150

MUR1660CTR

16

600

TO-220AB

1.7V@8A

1.5V@8A

35

5

0.05

250

-55 to +150

MUR2060CTF

20

600

TO-220F

1.7V@10A

1.5V@10A

50

10

0.5

150

-55 to +150

MUR2060CTFR

20

600

TO-220F

1.7V@10A

1.5V@10A

50

10

0.5

150

-55 to +150

MUR2060CT

20

600

TO-220AB

1.7V@10A

1.5V@10A

50

10

0.5

150

-55 to +150

MUR2060CTR

20

600

TO-220AB

1.7V@10A

1.5V@10A

50

10

0.5

150

-55 to +150

MUR3060PT

30

600

TO-247

1.6V@15A

1.4V@15A

50

10

0.5

300

-55 to +150

MUR3060PTR

30

600

TO-247

1.6V@15A

1.4V@15A

50

10

0.5

300

-55 to +150

MUR4060PT

40

600

TO-247

1.5V@20A

1.3V@20A

50

10

0.5

300

-55 to +150

MUR4060PTR

40

600

TO-247

1.5V@20A

1.3V@20A

50

10

0.5

300

-55 to +150

MURE4060CTF

40

600

TO-220F

1.7V@20A

1.5V@20A

35

10

0.5

150

-55 to +150

MURE4060CTFR

40

600

TO-220F

1.7V@20A

1.5V@20A

35

10

0.5

150

-55 to +150

MUR6060PT

60

600

TO-247

1.7V@30A

1.5V@30A

50

10

0.5

560

-55 to +150

MUR6060PTR

60

600

TO-247

1.7V@30A

1.5V@30A

50

10

0.5

560

-55 to +150

MUR1080CTF

10

800

TO-220F

2.0V@5A

1.8V@5A

35

1

0.25

100

-55 to +150

MUR1080CTFR

10

800

TO-220F

2.0V@5A

1.8V@5A

35

1

0.25

100

-55 to +150

MUR1680CTF

16

800

TO-220F

1.8V@8A

1.6V@8A

35

5

0.25

120

-55 to +150

MUR1680CTFR

16

800

TO-220F

1.8V@8A

1.6V@8A

35

5

0.25

120

-55 to +150

MUR2080CT

20

800

TO-220AB

2.3V@10A

2.0V@10A

35

5

0.25

120

-55 to +150

MUR2080CTR

20

800

TO-220AB

2.3V@10A

2.0V@10A

35

5

0.25

120

-55 to +150
